| Mercedes-Benz |
230 SL |
250 SL |
280 SL |
| Produced: |
1963–1967 |
1966–1968 |
1967–1971 |
| Chassis code: |
W113.042 |
W113.043 |
W113.044 |
| Engine: |
6-cylinder-inline engine (four-stroke), front-mounted |
| Engine code: |
M 127.II |
M 129.II |
M 130 |
| Bore x Stroke: |
82 mm (3.2 in) x 72.8 mm (2.9 in) |
82 mm (3.2 in) x 78.8 mm (3.1 in) |
86.5 mm (3.4 in) x 78.8 mm (3.1 in) |
| Displacement: |
2308 cc |
2496 cc |
2778 cc |
| Max. Power @ rpm: |
150 PS (110 kW; 150 hp) @ 5500 |
150 PS (110 kW; 150 hp) @ 5500 |
170 PS (130 kW; 170 hp) @ 5750 |
| Max. Torque @ rpm: |
196 N·m (145 lb·ft) @ 4200 |
216 N·m (159 lb·ft) @ 4200 |
240 N·m (180 lb·ft) @ 4500 |
| Compression Ratio: |
9.3: 1 |
9.5: 1 |
9.5: 1 |
| Fuel feed: |
Multi-port fuel injection, Bosch mechanical injection pump |
| Fuel tank capacity: |
65 L (17.2 US gal; 14.3 imp gal) |
82 L (21.7 US gal; 18.0 imp gal) |
| Valvetrain: |
SOHC, single roller chain |
SOHC, duplex chain |
| Cooling: |
Water |
| Gearbox: |
4-speed manual, 4-speed automatic or 5-speed manual
rear wheel drive, standard axle ratio 3.75:1 (on request 3.69:1 or 3.92:1) |
| Electrical system: |
12 volt |
| Front suspension: |
Double wishbones, coil springs, stabilising bar |
| Rear suspension:: |
Swing axle, radius arms, compensating spring, coil springs |
| Brakes: |
Disc/Drum brakes (Ø 253 mm (10.0 in) front, 230 mm (9.1 in) rear), power assisted |
Disc brakes all around (Ø 273 mm (10.7 in) front, 279 mm (11.0 in) rear), power assisted |
| Steering: |
Recirculating ball steering, on request power-assisted |
| Body structure: |
Sheet steel, monocoque (unibody) construction |
|
|
|
|
| Dry weight: |
1,300 kg (2,900 lb)
(hardtop + 49 kg (108 lb)) |
1,360 kg (3,000 lb)
(hardtop + 49 kg (108 lb)) |
| Loaded weight: |
1,650 kg (3,640 lb) |
1,715 kg (3,781 lb) |
|
|
Track front/
rear: |
1,485 mm (58.5 in) 1,485 mm (58.5 in) |
| Wheelbase: |
2,400 mm (94 in) |
|
|
| Length: |
4,285 mm (168.7 in) |
| Width: |
1,760 mm (69 in) |
| Height: |
1,305 mm (51.4 in) |
|
|
|
|
| Tyre/Tire sizes: |
185 HR 14 |
|
|
|
|
| Top speed: |
200 km/h (120 mph) |
195 km/h (121 mph) |
200 km/h (124 mph) |
| Fuel Consumption (estimate): |
15.0 litres per 100 kilometres (18.8 mpg-imp; 15.7 mpg-US) |
16.0 litres per 100 kilometres (17.7 mpg-imp; 14.7 mpg-US) |
16.5 litres per 100 kilometres (17.1 mpg-imp; 14.3 mpg-US) |
Price Germany
USA: |
22,200 DM
$7,506−$7,907, later $6,185−$6,587 |
22,800 DM
$6,485−$6,897 |
24,300 DM
$6,485−$6,897, later $7,469−$7,909 |
Mercedes-Benz W 113 on 1963–1971 vuosina valmistettu kaksipaikkainen avoauto, joka korvasi legendaarisen 300 SL (W 198) ja 190 SL (W 121 BII) mallin. Kaikki kyseisen mallin autot oli varusteltu suoralla 6-sylinterisellä monipisteruiskulla. Korin useat osat oli valmistettu alumiinista painon pudottamiseksi. Keveyden lisäksi matala ja lyhyt kori lisättynä laadukkaan alustan ja jarrujen kanssa antoi W 113-mallille loistavan ajettavuuden. Mallin klassinen keula myötäilee pitkälti legendaarista 300 SL avoautoa.
